LORD ROD ENDS - DYNAFLEX

Load Rating: 30 - 1,000 lbs (133 - 4450 N)

"All-axis motion control...effective suppression of noise and vibration..."

LORD Corporation elastomeric Rod Ends are easy to install and resist contamination, dirt and ozone. Available in stainless steel or aluminum, elastomeric rod ends provide all-axis motion control and isolation, offering distinct advantages over conventional rod ends.

One key difference is that there are no internal or moving parts or metal-to-metal contact points which can lead to poor performance in a harsh environment.

Typical Applications

Galley
Stowage bins
Bulkheads/monuments
Lavatory
Utility channels
Crew rests
Interior trim
Sensitive equipment

Catalog

Application analysis FORM

Lets Get Started!

Quick Quote

Ask A Question

Engineering Support

ENGINEERING ASSISTANCE - LORD ROD ENDS - DYNAFLEX

DeltaFlex is committed to providing you with the best engineering support experience possible.

"Frequently vibration isolation problems require a system engineering analysis..." - Put us to work for you.

Thank you for taking the time to learn about DeltaFlex and our LORD ROD ENDS - DYNAFLEX. Our applications engineer will help find the right solution for your application.

Our goal is to provide you with most efficient and effective engineering support. The more information you can provide upfront, the more diligent we can be in assisting you with your request.

We know that your time is valuable. So, we have filled-in some of the information for you.

Thank you...for putting DeltaFlex to work for you.

Engineering Support

Features & Benefits

Easy to install
Maintenance free
Need no lubrication
Will have no galling, brinelling or stress corrosion

Have no break-away force or slip/stick characteristics
Resist contaminants, dirt and ozone
Accommodate misalignment

Specs

Specs Metric

reset matrix

clear Part #	clear Thread Type	clear Thread Hand	clear Rubber Type	clear TYP DYN Stiffness (lb/in)	clear Load Rating @0.20" (lb)
J-21066-6	Male	Right	OR	1830	30
J-21066-8	Male	Right	OR	3840	60
J-21066-14	Male	Left	OR	1830	30
J-21066-16	Male	Left	OR	3840	60
J-21066-22	Female	Right	OR	1830	30
J-21066-24	Female	Right	OR	3840	60
J-21066-30	Female	Left	OR	1830	30
J-21066-32	Female	Left	OR	3840	60
J-21068-6	Male	Right	OR	3660	60
J-21068-8	Male	Right	OR	8960	140
J-21068-14	Male	Left	OR	3660	60
J-21068-16	Male	Left	OR	8960	140
J-21068-22	Female	Right	OR	3660	60
J-21068-24	Female	Right	OR	8960	140
J-21068-30	Female	Left	OR	3660	60
J-21068-32	Female	Left	OR	8960	140
J-21270-6	Male	Right	OR	8320	130
J-21270-8	Male	Right	OR	16875	270
J-21270-14	Male	Left	OR	8320	130
J-21270-16	Male	Left	OR	16875	270
J-21270-22	Female	Right	OR	8320	130
J-21270-24	Female	Right	OR	16875	270
J-21270-30	Female	Left	OR	8320	130
J-21270-32	Female	Left	OR	16875	270
J-21275-6	Male	Right	OR	10980	500
J-21275-8	Male	Right	OR	20480	1000
J-21275-14	Male	Left	OR	10980	500
J-21275-16	Male	Left	OR	20480	1000
J-21275-22	Female	Right	OR	10980	500
J-21275-24	Female	Right	OR	20480	1000
J-21275-30	Female	Left	OR	10980	500
J-21275-32	Female	Left	OR	20480	1000

reset matrix

clear Part #	clear Thread Type	clear Thread Hand	clear Rubber Type	clear TYP DYN Stiffness (N/mm)	clear Load Rating @0.20" (N)
J-21066-6	Male	Right	OR	320 N/mm	133 N
J-21066-8	Male	Right	OR	673 N/mm	267 N
J-21066-14	Male	Left	OR	320 N/mm	133 N
J-21066-16	Male	Left	OR	673 N/mm	267 N
J-21066-22	Female	Right	OR	320 N/mm	133 N
J-21066-24	Female	Right	OR	673 N/mm	267 N
J-21066-30	Female	Left	OR	320 N/mm	133 N
J-21066-32	Female	Left	OR	673 N/mm	267 N
J-21068-6	Male	Right	OR	641 N/mm	267 N
J-21068-8	Male	Right	OR	1569 N/mm	623 N
J-21068-14	Male	Left	OR	641 N/mm	267 N
J-21068-16	Left	OR	1569 N/mm	623 N
J-21068-22	Female	Right	OR	641 N/mm	267 N
J-21068-24	Female	Right	OR	1569 N/mm	623 N
J-21068-30	Female	Left	OR	641 N/mm	267 N
J-21068-32	Female	Left	OR	1569 N/mm	623 N
J-21270-6	Male	Right	OR	1457 N/mm	578 N
J-21270-8	Male	Right	OR	2955 N/mm	1201 N
J-21270-14	Male	Left	OR	1457 N/mm	578 N
J-21270-16	Male	Left	OR	2955 N/mm	1201 N
J-21270-22	Female	Right	OR	1457 N/mm	578 N
J-21270-24	Female	Right	OR	2955 N/mm	1201 N
J-21270-30	Female	Left	OR	1457 N/mm	578 N
J-21270-32	Female	Left	OR	2955 N/mm	1201 N
J-21275-6	Male	Right	OR	1923 N/mm	2225 N
J-21275-8	Male	Right	OR	3587 N/mm	4450 N
J-21275-14	Male	Left	OR	1923 N/mm	2225 N
J-21275-16	Male	Left	OR	3587 N/mm	4450 N
J-21275-22	Female	Right	OR	1923 N/mm	2225 N
J-21275-24	Female	Right	OR	3587 N/mm	4450 N
J-21275-30	Female	Left	OR	1923 N/mm	2225 N
J-21275-32	Female	Left	OR	3587 N/mm	4450 N
