LORD SURFACE-EFFECT MOUNTS ( Hystec Mounts )
Compression Load Range: 700 - 1,570 lbs (3,115 - 6,987 N)
"A more comfortable ride, superior product performance and reliable maintenance..."
As cab and engine mounts in on-and off-highway vehicles, surface-effect (SE) mounting systems meet the most demanding requirements for vibration isolation and noise attenuation while managing motion.
When conventional mounts are unable to satisfy vehicle requirements, SE mounts successfully control noise and vibration for a more comfortable ride, superior product performance and reliable maintenance.
Integrated Damping Principles
Integrating surface-effect damping principles with traditional rubber-bonded-to-metal technology, these mounts provide effective damping over large deflections and a wide range of frequencies. The systems are amplitude sensitive, responding to larger motions with greater damping forces for a wide range of rated loads. Easy in-the-field adjustable damping and decoupling capabilities reduce development/testing time and reduce the cost of systems optimization.
Simple in Construction
REQUEST A QUOTE - LORD SURFACE-EFFECT MOUNTS ( Hystec Mounts )
DeltaFlex is committed to providing you with the best customer experience possible.
Thank you for taking the time to learn about DeltaFlex and requesting a quote for our LORD SURFACE-EFFECT MOUNTS ( Hystec Mounts ).
Our goal is to provide you with most efficient and effective customer support. The more information you can provide upfront, the more diligent we can be in getting a quote to you or assisting you with your request.
We know that your time is valuable. So, we have filled-in some of the information for you.
Thank you...for putting DeltaFlex to work for you.
Quick Quote
CUSTOMER SUPPORT QUESTION - LORD SURFACE-EFFECT MOUNTS ( Hystec Mounts )
DeltaFlex is committed to providing you with the best customer support possible.
Thank you for taking the time to learn about DeltaFlex and our LORD SURFACE-EFFECT MOUNTS ( Hystec Mounts ).
Our goal is to provide you with most efficient and effective customer service. The more information you can provide upfront, the more diligent we can be in assisting you with your request.
We know that your time is valuable, so we have already filled-in some of the information for you.
Thank you...for putting DeltaFlex to work for you.
Ask A Question
ENGINEERING ASSISTANCE - LORD SURFACE-EFFECT MOUNTS ( Hystec Mounts )
DeltaFlex is committed to providing you with the best engineering support experience possible.
"Frequently vibration isolation problems require a system engineering analysis..." - Put us to work for you.
Thank you for taking the time to learn about DeltaFlex and our LORD SURFACE-EFFECT MOUNTS ( Hystec Mounts ). Our applications engineer will help find the right solution for your application.
Our goal is to provide you with most efficient and effective engineering support. The more information you can provide upfront, the more diligent we can be in assisting you with your request.
We know that your time is valuable. So, we have filled-in some of the information for you.
Thank you...for putting DeltaFlex to work for you.
Engineering Support
SE mounting systems are simple in construction, and the absence of pressure seals and fluids eliminates the possibility of leaks common with hydraulic mounts. In accelerated durability tests, these mounts have successfully passed more than 11 million cycles (the equivalent of 3 million kilometers or 2 million miles of Class 8 truck cab service) without significant wear.
Features & Benefits
|
|
|
clear
Part #
|
clear
Axial Static Load (lb.)
|
clear
Axial Static Deflection (in)
|
clear
Axial Static Stiffness (lb/in)
|
clear
Radial Static Stiffness (lb/in)
|
|---|---|---|---|---|
| SE-1100-1 | 700 | 0.30 in. | 1770 lbs./in. | 6850 lbs./in. |
| SE-1100-4 | 1140 | 0.30 in. | 2860 lbs./in. | 11420 lbs./in. |
| SE-1100-7 | 1570 | 0.30 in. | 6950 lbs./in. | 16000 lbs./in. |
