LORD BINOCULAR / SPLIT Rubber Engine Mounts
Compression Load Range: 1,000 - 1,500 lbs (4,450 - 6,675 N)
"For applications involving severe dynamic forces in the static load direction, as well as the rebound direction..."
LORD Binocular/Split Mounts are designed for applications involving severe dynamic forces in the static load direction, as well as the rebound direction.
These mounts are designed as front engine mounts, and accommodate frame racking and twisting while isolating vibration and absorbing shock.
Travel is limited in both directions by rubber in compression which provides snubbing.
Typical Applications
- Construction vehicles
- On-highway vehicles
- Off-highway vehicles
REQUEST A QUOTE - LORD BINOCULAR / SPLIT Rubber Engine Mounts
DeltaFlex is committed to providing you with the best customer experience possible.
Thank you for taking the time to learn about DeltaFlex and requesting a quote for our LORD BINOCULAR / SPLIT Rubber Engine Mounts.
Our goal is to provide you with most efficient and effective customer support. The more information you can provide upfront, the more diligent we can be in getting a quote to you or assisting you with your request.
We know that your time is valuable. So, we have filled-in some of the information for you.
Thank you...for putting DeltaFlex to work for you.
Quick Quote
CUSTOMER SUPPORT QUESTION - LORD BINOCULAR / SPLIT Rubber Engine Mounts
DeltaFlex is committed to providing you with the best customer support possible.
Thank you for taking the time to learn about DeltaFlex and our LORD BINOCULAR / SPLIT Rubber Engine Mounts.
Our goal is to provide you with most efficient and effective customer service. The more information you can provide upfront, the more diligent we can be in assisting you with your request.
We know that your time is valuable, so we have already filled-in some of the information for you.
Thank you...for putting DeltaFlex to work for you.
Ask A Question
ENGINEERING ASSISTANCE - LORD BINOCULAR / SPLIT Rubber Engine Mounts
DeltaFlex is committed to providing you with the best engineering support experience possible.
"Frequently vibration isolation problems require a system engineering analysis..." - Put us to work for you.
Thank you for taking the time to learn about DeltaFlex and our LORD BINOCULAR / SPLIT Rubber Engine Mounts. Our applications engineer will help find the right solution for your application.
Our goal is to provide you with most efficient and effective engineering support. The more information you can provide upfront, the more diligent we can be in assisting you with your request.
We know that your time is valuable. So, we have filled-in some of the information for you.
Thank you...for putting DeltaFlex to work for you.
Engineering Support
Features & Benefits
|
|
|
clear
Part #
|
clear
Rated Vertical Load
|
clear
Deflection @ Rated Load
|
clear
Vertical Stiffness
|
clear
Lateral Stiffness
|
|---|---|---|---|---|
| J-21246-6 | 1300 lbs. / 5783 N | 0.101 in. / 2.57 mm | 13,625 lbs/in / 2386 N/mm | 1950 lb/in / 341 N/mm |
| J-21246-12 | 1000 lbs. / 4448 N | 0.054 in. / 1.37 mm | 17,647 lbs/in / 3090 N/mm | 1400 lb/in / 245 N/mm |
| J-21246-13 | 1500 lbs. / 6672 N | 0.620 in. / 1.58 mm | 24,000 lbs/in / 4203 N/mm | 3300 lb/in / 578 N/mm |
